Servo BLS173SV brand FUTABA
New servos, brushless replaces the BLS153
With 15 mm thick only, this servo offers a huge torque output of 7.6 kg.
His linear is optimized for the steering of systems without the stabilizer bar and is, therefore, perfectly appropriate to the enslavement of trays cyclical helicopters category 500...600.
Programmable :
servos, S-BUS can be connected to the receivers usual with the PWM modulation. The addressing of the servos can intervene in various ways :
1. On the receiver S-BUS
2. With the programmer SBC-1 ref. 0100F1696 easy to handle
3. Using the PC software/S-Link and a USB adapter CIU-2, ref. 01001501 essential.
4. Connecting S. BUS transmitter (T14SG, T18MZ)
Also all the servos and S. BUS are also programmable.
The following functions are programmable :
• assignment of channel S. BUS
• reversing
• type of servo, normal - retractable landing gear
• soft start, on-off
• mode selection in case of failure of signal (hold last good signal received, or free)
• flexible operating of the servo, on / off
• position of the servo (tester servo)
• offset of the middle of the servo +/- 300 µs (approx. 30 degrees)
• speed of the servo, or 0.39...9 seconds to 45 degrees
• at the point of death
• development of the servo separately left and right, approx. 50...175%
Technical characteristics :
- speed : 0.10/60° below 7.4 V
- torque : 7.6 kg (7.4 V
- dimensions : 33x15x27.1mm
- weight : 28g
- power supply : 6.0 V to 7.4 V
