Receiver X8R-PCB EU LBT

The FRSKY X8R EU LBT receiver is a 2.4Ghz ACSST receiver with 8 PWM channels, up to 16 S-BUS channels and Smart Port telemetry.

This receiver is compatible with the FR-SKY DFT, DJT, DHT, DHT-U transmitter modules and the TARANIS X9D transmitter.

Product content:

• x1 Receiver X8R-PCB EU LBT

Technical Characteristics:

• x1 SBUS port (1 to 16 channels)
• x1 port Smart Port (telemetry)
• x1 RSSI port
• x8 PWM channels
• Possibility of combining two X8R receivers to obtain 16 PWM channels (D16 mode)
• Dimensions: 46.25x26.6x14.2mm
• Weight: 12.1g
• Supply voltage: 4.0V-10.0V
• Power consumption: 100mA
• Receiver range: 1.5km

https://www.flashrc.com/images/produits/22456/X8R.pdf
